MSI GeForce RTX 3060 VENTUS 2X 12 GB OC (912V397‑039)
MSI GeForce RTX 3060 VENTUS 2X 12 GB OC (model 912V397‑039) delivers robust mid-range gaming performance, leveraging NVIDIA’s Ampere RTX 3060 chip with 3,584 CUDA cores and a boosted 1,807 MHz clock (often auto-boosting close to 2,000 MHz) alongside 12 GB of GDDR6 memory on a 192‑bit bus (~360 GB/s bandwidth), making it ideal for high-quality 1080p–1440p gaming with ray tracing and DLSS capabilities.
Its compact dual-fan TORX Fan 3.0 cooler with Zero Frozr provides solid thermal management—temps typically hover between 70–80 °C under load, though they can hit mid-80s in less ventilated setups—and remains quiet at low temps, though users note the fans can get loud under load. Drawing around 170 W from a single 8‑pin PCIe connector (PSU ≥ 550 W recommended), the card supports DX12 Ultimate, OpenGL 4.6, 4K@120 Hz output (via 3× DisplayPort 1.4a + 1× HDMI 2.1), and comes pre-installed with MSI software like Afterburner, Dragon/Mission Center, and Predator for OC tuning and system monitoring . Overall, the Ventus 2X is a dependable, cost-effective RTX 3060 variant—delivering strong gaming performance and ray tracing at a reasonable price, especially with proper case airflow and optional undervolting to improve thermals and acoustics.
Description
MSI GeForce RTX 3060 VENTUS 2X 12 GB OC (912V397‑039)
Core Specifications
- GPU: NVIDIA GeForce RTX 3060 (Ampere architecture)
- CUDA Cores: 3,584
- Boost Clock: 1,807 MHz (factory overclocked)
- Memory: 12 GB GDDR6 @ 15 Gbps, 192‑bit bus — ~360 GB/s bandwidth
Power & Interface
- TDP / Power Draw: 170 W typical
- Power Input: Single 8‑pin PCIe connector
- Recommended PSU: ≥ 550 W
- Bus Interface: PCI Express 4.0 x16
Display Outputs & Resolution
- Outputs: 3 × DisplayPort 1.4a, 1 × HDMI 2.1 (4K@120 Hz support)
- Max Displays: 4 simultaneous outputs
- Max Resolution: 7,680 × 4,320
API & Feature Support
- DirectX Version: DirectX 12 Ultimate
- OpenGL: 4.6
- Ray Tracing: 2nd‑gen RT cores
- Tensor Cores: 3rd‑gen for DLSS & AI features
- VR-Ready, NVIDIA G‑Sync, Adaptive V‑Sync support
Cooling & Design
- Cooling: Dual-fan TORX Fan 3.0 with Zero Frozr (fan stops at low temps)
- Heatsink: Large fins with thermal pads for VRAM & VRMs
- Dimensions: ≈235 × 124 × 42 mm (2-slot design)
- Weight: ~675 g (card) / ~1,030 g (packaged)
Software & BIOS
- MSI Software: Includes Afterburner OC Scanner, Dragon Center, MSI Center, On‑Screen Display, Predator recording tool
- PCB: Custom design with reinforced circuits & power delivery
Practical Notes—Performance, Temperature & OC Headroom
- Boost Clock Behavior: Running above factory spec (≈2,000 MHz) via GPU Boost if thermals & power allow. This is normal.
- Temps: Typical loaded GPU temps range from 60–90 °C depending on case airflow and fan curves. Dual TORX Fan helps, but airflow is key. Undervolting or adjusting fan curves can help.
- Build Quality: Community feedback suggests Ventus line is reliable, but not top-tier on cooling compared to premium offerings—though still solid for mid-range builds.
Setup Recommendations
- Case Airflow: Ensure strong intake and exhaust (e.g., front + rear/top fans). Consider extra airflow if temps exceed 80 °C.
- Fan Curve Tuning: Use MSI Afterburner to create a more aggressive fan curve to keep temps in the 70’s under load.
- Undervolting: Lock voltage around 1000 mV if needed for stability or lower temps—proven trick.
- BIOS/Firmware: Keep GPU firmware and NVIDIA drivers up to date for efficiency and stability.
- Use MSI Center: Monitor temps, boost behavior, and optimize performance with OC scans and system tools.
Summary Table
| Spec Area | Details |
| GPU | RTX 3060 (3584 CUDA) @ 1807 MHz OC |
| VRAM | 12 GB GDDR6 @15 Gbps, 192‑bit |
| Power | 170 W (8‑pin), 550 W PSU suggested |
| Display Outputs | 3×DP 1.4a, 1×HDMI 2.1 (4K/120 Hz) |
| Cooling | Dual TORX Fan 3.0, Zero Frozr, thermal pads |
| Features | DX12 Ultimate, RT/ Tensor cores, DLSS, VR‑ready |
| Size/Weight | 235×124×42 mm, ~675 g |
| Software | Afterburner OC, MSI Center, Dragon Center, Predator |
MSI VENTUS 2X 12 GB OC offers strong performance for 1080p–1440p gaming with full RTX features. Its compact dual-fan setup is efficient if paired with good case airflow. With some tuning (fan curves/undervolting), you can optimize thermals and noise.
