Key Features

• Dual-Sided Printing: Reliable and efficient duplex printing for professional-grade ID cards.
• FINE™ Imaging Technology: Delivers high-quality prints with sharp and vibrant details.
• Upgradeable & Flexible: Field-upgradable options for flipper modules, laminators, and Ethernet connectivity.
• Fast and Quiet: Designed for quick operation with minimal noise, suitable for office environments.
• User-Friendly Interface: Intuitive 2-line LCD display and 2 LED buttons for easy control.
• Low Cost Per Print: Economical printing solution with advanced consumables.

Printing Specifications

• Print Type: Dye-Sublimation for color and thermal transfer for monochrome.
• Print Area: Edge-to-edge printing for seamless card coverage.
• Resolution: 300dpi for sharp and detailed images.
• Dual-Sided Printing: Available as an optional upgrade with a flipper module.

Card Specifications

• Card Feeding: Automatic card feeding for efficient workflow.
• Card Size:
  • ISO CR80 (standard credit card size).
  • ISO CR79 (optional, factory-installed).
• Card Thickness:
  • From 0.38mm (15mil) to 1.0mm (40mil).
• Card Type: PVC, PET, Composite PVC. Compatible with transparent cards.

Print Speed

• Monochrome: Up to 5 seconds per card (720 cards/hour).
• Full Color (YMCKO): Maximum 17 seconds per card (200 cards/hour).

Capacity

• Input Hopper:
  • Standard: 100 cards.
  • With cover open: 200 cards.
• Output Hopper:
  • Front: 40 cards.
  • Rear: 100 cards (optional rear-side stacker available).

Consumables

• Color Ribbons:
  • YMCKO (250 cards/roll).
  • YMCFKO with UV panel (200 cards/roll).
  • HYMCKO (350 cards/roll).
• Monochrome Ribbons:
  • KO (600 cards/roll).
  • K, W, B, R, MG, MS, SO (1,200 cards/roll for each).
  • Available in black, white, blue, red, metallic gold/silver, and scratch-off.

System Features

• Memory: 64MB RAM.
• Display: 2-line LCD for operational feedback.
• Control Panel: 2 LED buttons for ease of use.
• Supported Platforms: Windows 7/8/10, Mac OS, and Linux.
• Communication: USB (standard) and Ethernet (optional).
• Power Supply: Free voltage (AC 100/220V, 50~60Hz).
• Power Consumption: 48W.
• Operating Temperature & Humidity:
  • Temperature: 15–35°C.
  • Humidity: 35–70%.

Dimensions & Weight

• Dimensions:
  • Millimeters: 165 x 390 x 210 (WxLxH).
  • Inches: 6.5 x 15.4 x 8.3 (WxLxH).
• Weight: 4.5kg (10 lbs).

Encoding Options

• Magnetic Stripe Encoding: ISO 7811 (Track I, II, III Read/Write, HiCo/LoCo), JIS II.
• Contact Chip Encoding: ISO 7816 (ID-1).
• Contactless Encoding: MIFARE, ISO 14443 (Type A/B), ISO 15693, DESFIRE, iCLASS.

Certifications

• Fully certified for reliable, durable, and secure ID card production.

Applications

• Employee ID Cards
• Student ID Cards
• Payment Cards
• Health Cards
• Resort Pass Cards
• Loyalty Cards
• Transport Pass Cards
• Event Cards

Warranty

• 1-year warranty ensures reliable, long-term operation.

This IDP SMART-51D is an ideal choice for organizations seeking a cost-effective, efficient, and durable dual-sided ID card printing solution. Let me know if you need additional details or further assistance
