Description

Cisco CBS350-8P-E-2G-UK – 8-Port Gigabit PoE Managed Switch

Cisco CBS350-8P-E-2G-UK is a high-performance managed switch designed for small to medium-sized business networks. With 8 gigabit RJ-45 PoE+ ports and 2 gigabit SFP (or combo) uplink ports, this switch delivers both data and power to connected devices like IP cameras, wireless access points and VoIP phones, while offering advanced management features, robust security and flexible deployment options.

Product Features

8 × Gigabit PoE+ Ports

Enables powering and networking of devices such as wireless access points, network cameras and VoIP phones via a single cable, reducing infrastructure complexity and cost.

2 × Gigabit SFP Uplinks (Combo)

Provides two uplink ports that support either RJ-45 or SFP modules — ideal for fiber or long-reach uplink connections to a core network or another switch.

Advanced Managed Layer 2+ / Layer 3 Capabilities

Supports features such as VLANs, static routing, link aggregation (LACP), ACLs, QoS, and advanced network segmentation — giving you enterprise-grade control in a business-friendly form factor.

PoE Budget & Power Delivery

Offers a total PoE power budget sufficient to power multiple devices with up to 30 W per port (within the overall budget) under the IEEE 802.3af/at standards.

Silent & Efficient Design

Typically fanless (especially in low-port-count models), making it suitable for quiet office or classroom environments. Energy-efficient design helps reduce operational costs.

Flexible Deployment Options

Can be mounted on a desktop, wall or rack (with optional kit) and supports both copper and fibre uplinks, making it versatile for branch offices, retail stores or campus deployments.

Product Specifications

• Model: Cisco CBS350-8P-E-2G-UK
• Ports:
  • 8 × 10/100/1000 Mbps RJ-45 (PoE+)
  • 2 × Gigabit SFP or RJ-45/SFP combo uplink ports
• PoE Standards: IEEE 802.3af / IEEE 802.3at (PoE+)
• Total PoE Power Budget: ~67 W
• Switching Capacity (Backplane): ~20 Gbps
• Forwarding Rate: ~14.88 Mpps (64-byte packets)
• MAC Address Table Size: ~16K entries
• VLAN Support: Up to ~4,094 VLANs
• Management Interfaces: Web UI, CLI, SNMP v1/v2c/v3, SSH, RADIUS/TACACS+
• Physical Dimensions: ~268 × 185 × 44 mm (W×D×H)
• Operating Temperature: 0 °C to ~50 °C (typical)
• Mounting: Desktop, wall-mountable, optional rack-kit support
